Watt Meter
All Instruments comply with IEC 60051 for performance, accuracy and overloads Case and frame using material thermoplastic (ABS V0) white, with IP50 Ingress Protection.
| Measuring range/Rated voltage Connetion/Accuracy class System Internal consumption Frame size/Weight |
50Hz/380V,100v,110V 20% 3 phase 4 wire/1.5 Moving coil electronic frequency measurement Voltage path 1.75W/22VA, current path 0.5w/0.5VA 96x96mm/230gr |
